GMC Forward Control P3500 (1985-1999) fuel inject ctrl Wiring diagram
This page shows the only wiring diagram for the component.fuel inject ctrl, which is found in the car GMC Forward Control P3500 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel inject ctrl (1 of 1)
"SERV THROTTLE SOON" IND
18 19 PNK WIRE
A/C ENABLE GROUND GROUND 451 551
ANTILOCK BRAKES SYSTEM
BATTERY
BATTERY WASTEGATE SOL CTRL ESO SOLENOID CTLR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
ENG 1 FUSE 15
ESO CTRL
FUEL HEATER (TOP REAR OF ENGINE)
FUEL INJECT CTRL
FUSIBLE LINK
FUSIBLE LINKS
GLOW PLUG 1
GLOW PLUG 2
GLOW PLUG 3
GLOW PLUG 5 GLOW PLUG 7
GLOW PLUG 6 GLOW PLUG 4
GLOW PLUG 8
GLOW PLUG OUT
GLOW PLUG RELAY (TOP REAR OF INTAKE MANIFOLD)
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN AND START
I/P FUSE BLOCK
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK IGNITION WIRE
PNK PNK 439 439 IGNITION IGNITION BATTERY MIL IND CTRL WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF DRIVER'S ISLAND)
PPL
RED WIRE
RELAY CTRL
WASTEGATE SOLENOID
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 6.5l (vin f)s, motor home chassis (4 of 4) -> FUEL INJECT CTRL
