GMC Forward Control P3500 (1985-1999) (forward lamps harness, wiring diagram

This page shows the only wiring diagram for the component.(forward lamps harness,, which is found in the car GMC Forward Control P3500 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

(forward lamps harness, wiring diagram (1 of 1)

BLK WIRE GRN WIRE HEADLAMP DIMMER SWITCH HI BEAM INDICATOR HI LO HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT HEADLAMP ASSEMBLY HI LEFT LOWER HEAD- LAMP (W/ HPR) LIGHT SWITCH LT GRN WIRE OFF OFF HEAD HEAD PARK PARK RIGHT HEADLAMP ASSEMBLY LO HI RIGHT LOWER HEAD- LAMP (W/ HPR) TAN WIRE YEL WIRE

Go to component -> Headlamps circuit, motor home chassis -> (FORWARD LAMPS HARNESS,
