GMC Forward Control P3500 (1985-1999) canadian models only Wiring diagram
This page shows the only wiring diagram for the component.canadian models only, which is found in the car GMC Forward Control P3500 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram canadian models only (1 of 1)
1996 VFTC
6.5L VIN Y
A/C COMPRESSOR CLUTCH RELAY
AUTOMATIC TRANSMISSION
AUX FUSE
BACK UP LAMPS SWITCH
BRN WIRE
CANADIAN MODELS ONLY
CAVITY A)
DAYTIME RUNNING LAMP (DRL) RELAY
DAYTIME RUNNING LAMPS (DRL) CONTROL MODULE
DIESEL
ECM 1 FUSE
FROM IGNITION SWITCH
FUEL INJECTION PUMP FUEL SHUT-OFF SOLENOID
GAS
GAS MODELS ONLY
GAUGES FUSE
GENERATOR GENERATOR
HOT IN RUN, START
HTR BUS
HTR FUSE
I-3 FUSE
I/P FUSE BLOCK (DASH PANEL PROVIDED BY BODY BUILDER) (BODY BUILDER INSTALLED)
IGN BUS
INSTRUMENT CLUSTER
MANUAL TRANSMISSION
ORG/ WIRE
P/B BOOSTER FLUID FLOW, PRESSURE ALARM
PARK/ NEUTRAL POSITION (PNP), BACKUP LAMPS SWITCH
PNK PNK WIRE
PNK WIRE
SEAT BELT ALARM INSTRUMENT CLUSTER
THIS CAN PLUG INTO
TORQUE CONVERTER CLUTCH (TCC), STOP LAMPS SWITCH
TRANSMISSION CONTROL MODULE (TCM) FUEL INJECTION PUMP FUEL SHUT-OFF SOLENOID
TURN SIGNAL FLASHER
TURN-B/U FUSE
VEHICLE CONTROL MODULE (VCM)
VEHICLE SPEED SENSOR (VSS) BUFFER
W/BRAKE WARNING INDICATOR SYSTEM
Go to component -> Power distribution circuit, commercial chassis (4 of 5) -> CANADIAN MODELS ONLY
