GMC Forward Control P3500 (1985-1999) brake pressure warning switch wiring diagram
This page shows the only wiring diagram for the component.brake pressure warning switch, which is found in the car GMC Forward Control P3500 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
brake pressure warning switch wiring diagram (1 of 1)
ACCY
ACCY BULB TEST LOCK
AUDIO ALARM MODULE
AUTO APPLY PARK BRAKE
AUX
AUX CIRCUIT BREAKER
AUXILIARY COOLING FAN RELAY
BATTERY
BATTERY JUNCTION BLOCK
BLK WIRE
BLK/RED WIRE
BRAKE PRESSURE WARNING SWITCH
BRN WIRE
BRN/WHT WIRE
BULB TEST
DAYTIME RUNNING LAMPS AUXILIARY COOLING FAN RELAY
DAYTIME RUNNING LAMPS MODULE DAYTIME RUNNING LAMPS RELAY
DK GRN WIRE
DOME LAMP
ECM-BAT FUSE ACC-RADIO FUSE
FROM PANEL DIMMER SWITCH ASSEMBLY (INTERIOR LIGHTS SYSTEM)
FUEL PUMP OIL PRESSURE SWITCH FUEL PUMP RELAY POWERTRAIN CONTROL MODULE
FUSE BLOCK
FUSIBLE
FUSIBLE LINK
GAGES FUSE
GENERATOR
GRY WIRE
HAZARD FLASHER
HEADLIGHT SWITCH ASSEMBLY
HORN RELAY
HTR FUSE
I/P CLUSTER
IGNITION SWITCH
INSTR-LPS LPS BUS FUSE
LINK
LOCK
LOCK OFF
OFF
ORG/ WIRE
PARK BRAKE WARNING SWITCH
PCM
PNK WIRE
PNK/ WHT WIRE
PPL
PWR CIRCUIT BREAKER
RED WIRE
RELAY
RUN WIRE
SHUNT
STARTER MOTOR
STOP- HZ FUSE
STOPLAMP SWITCH
TAIL LPS FUSE HORN/DM FUSE
TAN/WHT WIRE
TO ALT, ECM-CRANK, TURN-B/U, TRANS, INJECTOR FUSES AND IGNITION COIL
TRANSMISSION INSTRUMENT AUDIO POSITION CLUSTER ALARM INDICATOR MODULE LAMP
WHT PNK/ WIRE
WHT WIRE
WIPER FUSE
WIPER SWITCH
Go to component -> Power distribution circuit, motorhome chassis (1 of 2) -> BRAKE PRESSURE WARNING SWITCH
