GMC Forward Control P3500 (1985-1999) brake ind drl ind Wiring diagram

4 13 PNK WIRE A/T ABS IND. ACCY BULB TEST LOCK OFF ANTI-LOCK BRAKES SYSTEM AUTO PARK IND. BLK WIRE BLK/WHT WIRE BRAKE IND DRL IND BRN/WHT WIRE CHECK GAUGES IND COOLANT TEMPERATURE GAUGE DIESEL DK BLU WIRE DK GRN WIRE DOOR AJAR IND ECM 1 FUSE 12 ENGINE CONTROLS OR STARTING/ CHARGING SYSTEM ENGINE CONTROLS SYSTEM ENGINE CONTROLS SYSTEM ENGINE CONTROLS SYSTEM ENGINE COOLANT LEVEL SWITCH (ON LOWER LEFT END OF RADIATOR SURGE TANK) FUEL GAUGE FUEL SENDER (ON TOP OF FUEL TANK) GAS GAUGES FUSE 8 GRY WIRE GRY/BLK WIRE HEADLIGHTS SYSTEM HI-BEAM IND HOT IN RUN OR START I/P FUSE BLOCK (BEHIND DASH PANEL) (BODY BUILDER INSTALLED) IGNITION SWITCH ILLUMINATION IN-LINE CONNECTOR PROVISIONS FOR BODY BUILDER INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM WARNING SYSTEMS LEFT TURN IND LOW COOLANT IND LT BLU WIRE LT GRN (OR WHT) WIRE LT GRN WIRE LT GRN/BLK WIRE MALFUNCTION IND. LAMP (MIL) (SERVICE ENGINE SOON IND) OIL PRESSURE GAUGE PNK WIRE PPL PPL DIESEL PPL GAS PPL RIGHT TURN IND RUN WIRE SEAT BELT IND SERVICE THROTTLE SOON IND SPEEDOMETER TACHOMETER TAN WIRE TAN/WHT WIRE VEHICLE CONTROL MODULE (ON LEFT SIDE OF RADIATOR SUPPORT) VOLTMETER VSS CALIBRATOR (LEFT SIDE OF DRIVER'S ISLAND, UNDER RELAY BRACKET) WAIT TO START IND WATER IN FUEL IND WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
