GMC Envoy II (2001-2009) Transfer case circuit, 2 speed

1569 1563 1560 1694 1555 LOCK SOL 2 HI IND NEUTRAL IND 2 HI 4 HI 4 LO 4.2L 401 400 PPL FRONT SIG LO FRONT SIG HI 850 1640 1552 1553 GROUND BATTERY MOTOR CTRL A MOTOR CTRL B ATC FUSE AXLE SW BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ENCODER ENCODER SIG FRONT AXLE ACTUATOR (ON INNER FLANGE OF RIGHT FRONT AXLE) FUSE GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR START INSTRUMENT PANEL CLUSTER (IPC) LOGIC LT BLU WIRE LT GRN/BLK WIRE MOTOR BRAKE NEUT NEUTRAL ORG/ WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) PPL PPL/WHT WIRE REAR FUSE BLOCK (BELOW LEFT REAR SEAT) REAR SIG HI REAR SIG LO RED WIRE RUN WIRE SERVICE SPLICE PACK PPL (BEHIND LEFT SIDE OF DASH) TAN WIRE TAN/BLK WIRE THEFT DETERENT CONTROL MODULE TRANSFER CASE ENCODER MOTOR (ON TOP OF TRANSFER CASE) TRANSFER CASE SHIFT CONTROL MODULE (BEHIND LOWER LEFT SIDE OF DASH) TRANSFER CASE SHIFT CONTROL SWITCH UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL) UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL) IGN E FUSE WHT WIRE YEL WIRE
