GMC Envoy II (2001-2009) trans range sw c press sw sig a tcc sol valv ctrl pnk Wiring diagram

2-3 SS VALV CTRL 3-2 SS VALV CTRL ACCESSORY VOLT BLK WIRE BLK/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE FRONT HI SIG SERIAL DATA (-) SERIAL DATA (+) GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN HOT IN RUN OR START IGN E FUSE 22 LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE PARK/NEUTRAL POSITION (PNP) SWITCH (ON LOWER LEFT SIDE OF TRANSMISSION) PNK 12 13 WIRE PNK WIRE PPL/WHT WIRE PRESS SW SIG B LOW REF TRANS RANGE SW B REAR TCM FUSE 35 FUSE BLOCK (BELOW LEFT REAR SEAT) RED WIRE RED/BLK WIRE ST/LP FUSE 12 STOP LAMP SWITCH (ON BRAKE PEDAL ASSEMBLY) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCM/ CANISTER FUSE 15 TFT SENS SIG TRANS FUSE 53 TRANS RANGE SW A LOW REF IGN 1 VOLT BATT VOLT PRESS SW SIG C TRANS RANGE SW C PRESS SW SIG A TCC SOL VALV CTRL PNK WIRE TRANSMISSION CONTROL MODULE (TCM) (LEFT FRONT OF ENGINE) UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL) VEH STOP FUSE 34 VEHICLE SPEED SENSOR (VSS) VSS HIGH SIG PC SOL VALV LO CTRL WHT WIRE YEL WIRE YEL/BLK WIRE
