GMC Envoy II (2001-2009) sun roof switch open signal Wiring diagram
This page shows the only wiring diagram for the component.sun roof switch open signal, which is found in the car GMC Envoy II (2001-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sun roof switch open signal (1 of 1)
BATTERY POSITIVE VOLTAGE
BLK/PPL WIRE
BRN WIRE
CLOSE OPEN
DK BLU WIRE
GROUND
HOT AT ALL TIMES
LT BLU WIRE
NCA WIRE
ORG/ WIRE
PPL
RAP FUSE SUPPLY VOLTAGE
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
SUN ROOF SWITCH
SUN ROOF SWITCH CLOSE SIGNAL SUN ROOF SWITCH LOW REFERENCE
SUN ROOF SWITCH OPEN SIGNAL
SUN-ROOF MOTOR
SUNROOF FUSE 28
WHT WIRE
YEL/RED WIRE
