GMC Envoy II (2001-2009) fan relay 45 hdm relay 46 Wiring diagram
This page shows the only wiring diagram for the component.fan relay 45 hdm relay 46, which is found in the car GMC Envoy II (2001-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fan relay 45 hdm relay 46 (1 of 1)
4.2L
5.3L, 6.0L 4.2L
A/C COMPRESSOR CLUTCH ASSEMBLY
BARE
BLK WIRE
BRAKE FLUID LEVEL SWITCH
DK GRN WIRE
EAP RELAY 49
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE CONTROL MODULE (ECM)
F/PUMP RELAY 41
FAN RELAY 45 HDM RELAY 46
FRONT AXLE ACTUATOR
FRONT PASSENGER DOOR MODULE (FPDM) VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
GMC, BUICK
HIGH BEAM LOW BEAM
HOOD AJAR SWITCH
LEFT CORNERING LAMP
LEFT FRONT FOG LAMP
LEFT FRONT MARKER LAMP
LEFT FRONT PARK LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP
MASS AIRFLOW/ INTAKE AIR TEMPERATURE SENSOR
ONSTAR MICROPHONE GROUND SHIELD 2
PARK/ NEUTRAL POSITION (PNP) SWITCH
PASSENGER LUMBAR ADJUSTER SWITCH
PASSENGER SEAT ADJUSTER SWITCH
POWERTRAIN CONTROL MODULE (PCM)
REGULATED VOLTAGE CONTROL MODULE
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR WINDOW SWITCH
SECONDARY AIR INJECTION (AIR) SOLENOID
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
W/ 2 SPEED PUSH BUTTON CONTROL
W/ DELUXE SEATS
W/ FRONT FOG LAMPS
W/ GPS 1
W/ WIRING PROVISIONS
WHT WIRE
Go to component -> Ground distribution circuit (2 of 4) -> FAN RELAY 45 HDM RELAY 46
