GMC Envoy II (2001-2009) bare drain wire rr spkr out - lr spkr out - b+ Wiring diagrams

1 2 3 4 5 6 PPL AMP FUSE 11 AUDIO AMPLIFIER (ON RIGHT SIDE OF CARGO AREA, BARE BARE DRAIN WIRE RR SPKR OUT - LR SPKR OUT - B+ BEHIND TRIM PANEL) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK) BRN WIRE DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL LEFT FRONT DOOR SPEAKER LEFT FRONT I/P SPEAKER LEFT REAR DOOR SPEAKER LR SPKR OUT + RR SPKR OUT + LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PNK BARE WIRE PNK WIRE PPL RADIO CONTROL SIGNAL REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RIGHT FRONT DOOR SPEAKER RIGHT FRONT I/P SPEAKER RIGHT REAR DOOR SPEAKER SEEK DOWN SEEK PROG SEEK UP SEEK VOICE SERIAL DATA SOURCE DOWN SOURCE UP STEERING WHEEL) SUPPLY VOLTAGE TAN WIRE UPPER LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY UPPER RIGHT STEERING WHEEL CONTROL SWITCH ASSEMBLY VOLUME DOWN VOLUME UP WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE

1 2 3 4 5 6 PPL AMP FUSE 11 AUDIO AMPLIFIER (ON RIGHT SIDE OF CARGO AREA, BEHIND TRIM PANEL) BARE BARE DRAIN WIRE RR SPKR OUT - LR SPKR OUT - B+ BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK) BRN WIRE DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL LEFT FRONT DOOR SPEAKER LEFT FRONT I/P SPEAKER LEFT REAR DOOR SPEAKER LR SPKR OUT + RR SPKR OUT + LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PNK BARE WIRE PNK WIRE PPL RADIO CONTROL SIGNAL REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RIGHT FRONT DOOR SPEAKER RIGHT FRONT I/P SPEAKER RIGHT REAR DOOR SPEAKER SEEK DOWN SEEK PROG SEEK UP SEEK VOICE SERIAL DATA SOURCE DOWN SOURCE UP STEERING WHEEL) SUPPLY VOLTAGE TAN WIRE UPPER LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY UPPER RIGHT STEERING WHEEL CONTROL SWITCH ASSEMBLY VOLUME DOWN VOLUME UP WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE
