GMC Envoy II (2001-2009) 1047 4240 class 2 serial data battery wiring diagram

1047 4240 CLASS 2 SERIAL DATA BATTERY 1340 1450 BATTERY GROUND 4140 1046 BATTERY CLASS 2 SERIAL DATA BATTERY GROUND BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DDM FUSE 10 DK BLU WIRE DOWN UP DRIVER DOOR MODULE (DDM) (BELOW DRIVER'S DOOR SWITCH PANEL) FOLDING/ TELESCOPING MOTOR FRONT PASSENGER DOOR MODULE (FPDM) (BELOW FRONT PASSENGER'S DOOR SWITCH PANEL) GRY WIRE HEATING ELEMENT HOT AT ALL TIMES HVAC CLASS 2 SERIAL DATA HVAC CONTROL MODULE (CENTER OF DASH) LEFT HORIZONTAL LEFT UP HORIZONTAL VERTICAL PASSENGER OUTSIDE REARVIEW MIRROR LOGIC LT BLU WIRE LT DOORS CIRCUIT BREAKER 2 MIRROR EXTEND NCA WIRE ORG/ WIRE OUTSIDE REARVIEW MIRROR SWITCH PASS DRIVER PDM FUSE 12 PNK WIRE PPL R DEF REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RED WIRE RIGHT LEFT RT DOORS CIRCUIT BREAKER 1 TAN WIRE UP VERTICAL DRIVER OUTSIDE REARVIEW MIRROR WHT WIRE WHT/BLK WIRE WHT/RED WIRE
