GMC Envoy I (1997-2000) sensor ret sensor data wiring diagram
This page shows the only wiring diagram for the component.sensor ret sensor data, which is found in the car GMC Envoy I (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sensor ret sensor data wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE FUSE 3
GRD BATTERY SERIAL DATA GRD SENSOR PWR IGNITION
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSLOCK SENSOR (AT IGNITION SWITCH)
RED WIRE
RED/WHT WIRE
SENSOR RET SENSOR DATA
SPLICE PACK
TBC FUSE
TRUCK BODY CONTROL MODULE (BEHIND DASH, ON HEATER)
UNDERHOOD BUSSED ELECTRICAL CENTER
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit -> SENSOR RET SENSOR DATA
