GMC Cutaway G3500 (2012-2013) aux stop lamp fuse wiring diagram
This page shows the only wiring diagram for the component.aux stop lamp fuse, which is found in the car GMC Cutaway G3500 (2012-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
aux stop lamp fuse wiring diagram (1 of 1)
16 CM FROM UNDERHOOD
4 SPEED A/T 6 SPEED A/T
AUTOMATIC TRANSMISSION
AUX STOP LAMP FUSE
BLK WIRE
BLK/WHT WIRE
BREAKOUT TOWARDS INSTRUMENT PANEL CLUSTER)
BREAKOUT)
BRK SW FUSE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
CUTAWAY
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
ENGINE CONTROL MODULE (ECM)
EXCEPT 4.3L 4.3L
HEAD PARK AUTO
HEADLAMP, PANEL DIMMER
HOT AT ALL TIMES
HOT W/ RUN/CRANK RELAY 15 ENERGIZED
IGN
INSTRUMENT PANEL CLUSTER (IPC)
IPC FUSE
LEFT FRONT SIDE MARKER LAMP
LEFT PARK/ TURN SIGNAL LAMP
LEFT TURN IND
LOGIC
LT BLU WIRE
LT BLU/WHT WIRE
OFF
PNK WIRE
PROVISIONAL
RIGHT RIGHT PARK/ FRONT SIDE TURN MARKER SIGNAL LAMP LAMP
RIGHT TURN IND
SER DATA
STOP LAMP SWITCH (BEHIND LEFT SIDE OF DASH, ABOVE BRAKE PEDAL)
STOP LAMPS PCB RELAY
SWITCH
TRANSMISSION CONTROL MODULE (TCM) (LEFT FRONT CORNER OF ENGINE COMPT)
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> AUX STOP LAMP FUSE
