GMC Canyon III (2022-2024) w/o integrated digital audio system Wiring diagrams

This page contains all the electrical diagrams for the component. w/o integrated digital audio system, in which he is found in the car GMC Canyon III (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram w/o integrated digital audio system (1 of 4)

Wiring diagram w/o integrated digital audio system for GMC Canyon III (2022-2024) (1 of 4)

Get access

1-BK 1-CU 1-VT 2-BK 2-CU 2-VT AM/FM AM/FM 4-BK AUTOMOTIVE AUDIO AUTOSAR CAN BUS (+) 5 SERIAL DATA AUXILIARY WIRELESS COMMUNICATION INTERFACE ANTENNA BACKUP LAMP CTRL BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/WHT WIRE CELL CHEVROLET COAX COAX BK COAX BU COMMUNICATION CENTER CALL SWITCH COMPUTER DATA LINES SYSTEM DAB DAB 3-BK DATA 1 (+) DAY NIGHT LED CTRL ETHERNET BUS 2 (-) ETHERNET BUS 4 (-) FORWARD COLLISION ALERT LED CTRL GMC GPS/CELL GRN WIRE GRN/BLK WIRE GRN/GRY WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/YEL WIRE LANE DEPARTURE WARNING CIRCUIT LIN BUS 1 NAVIGATION SYSTEM ONSTAR PHONE RADIO REAR VIEW DRIVER INFORMATION CAMERA SOS VIDEO PROCESSING CONTROL MODULE VIDEO PROCESSING MODULE COAXIAL VIDEO SIG BU W/ ALL AROUND VISION CAMERA W/ INTEGRATED DIGITAL AUDIO SYSTEM W/O ALL AROUND VISION CAMERA W/O INTEGRATED DIGITAL AUDIO SYSTEM WHT WIRE WIFI BK XM 2-BK YEL/VIO WIRE

Go to component -> Navigation circuit, w/ amplifier (1 of 5) -> W/O INTEGRATED DIGITAL AUDIO SYSTEM

Wiring diagram w/o integrated digital audio system (2 of 4)

Wiring diagram w/o integrated digital audio system for GMC Canyon III (2022-2024) (2 of 4)

Get access

1-BK 1-CU 1-VT 2-BK 2-BK XM 2-CU 2-VT 3-BK DAB 4-BK AM/FM AM/FM AUTOMOTIVE AUDIO AUTOSAR CAN BUS (+) 5 SERIAL DATA AUXILIARY WIRELESS COMMUNICATION INTERFACE ANTENNA BACKUP LAMP CTRL BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE CELL CHEVROLET COAX COAX BK COAX BU COMPUTER DATA LINES SYSTEM DAB DATA 1 (+) DAY NIGHT LED CTRL ETHERNET BUS 2 (-) ETHERNET BUS 4 (-) FORWARD COLLISION ALERT LED CTRL GMC GPS/CELL GRN WIRE GRN/BLK WIRE GRN/GRY WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/YEL WIRE INSTRUMENT PANEL LEFT RADIO FRONT SPEAKER INSTRUMENT PANEL RIGHT RADIO FRONT SPEAKER LANE DEPARTURE WARNING CIRCUIT LEFT RADIO FRONT SIDE DOOR SPEAKER LEFT RADIO REAR SIDE DOOR SPEAKER LF SPKR (-) CTRL (1) LIN BUS 1 LR SPKR (-) CTRL NAVIGATION SYSTEM RADIO REAR VIEW DRIVER INFORMATION CAMERA RF SPKR (-) CTRL (1) RIGHT RADIO FRONT SIDE DOOR SPEAKER RIGHT RADIO REAR SIDE DOOR SPEAKER RR SPKR (-) CTRL VIDEO PROCESSING CONTROL MODULE VIDEO PROCESSING MODULE COAXIAL VIDEO SIG BU W/ ALL AROUND VISION CAMERA W/ INTEGRATED DIGITAL AUDIO SYSTEM W/O ALL AROUND VISION CAMERA W/O INTEGRATED DIGITAL AUDIO SYSTEM WHT WIRE WIFI BK YEL WIRE YEL/BLK WIRE

Go to component -> Navigation circuit, w/o amplifier (1 of 4) -> W/O INTEGRATED DIGITAL AUDIO SYSTEM
