GMC Canyon III (2022-2024) window lift switch Wiring diagram
This page shows the only wiring diagram for the component.window lift switch, which is found in the car GMC Canyon III (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram window lift switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DOWN
EXPRESS
GRN/BLK WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/VIO WIRE
HAZARD WARNING SWITCH
ILL
LEFT REAR SIDE DOOR WINDOW REGULATOR MOTOR
LEFT REAR SIDE DOOR WINDOW SWITCH
LOGIC
LOGIC ILL
PASSENGER FRONT SIDE DOOR WINDOW REGULATOR MOTOR
PASSENGER FRONT SIDE DOOR WINDOW SWITCH
RED/BLU WIRE
RED/GRY WIRE
RIGHT REAR SIDE DOOR WINDOW REGULATOR MOTOR
RIGHT REAR SIDE DOOR WINDOW SWITCH
WINDOW LIFT IND
WINDOW LIFT SWITCH
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Power windows circuit (2 of 2) -> WINDOW LIFT SWITCH
