GMC Canyon III (2022-2024) w/ vehicle communication Wiring diagrams
This page contains all the electrical diagrams for the component. w/ vehicle communication, in which he is found in the car GMC Canyon III (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ vehicle communication (1 of 2)
B+ VOLT
BLK WIRE
BLK/WHT WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN/YEL WIRE
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LIN BUS 16
LOGIC
PASSENGER DOOR LOCK SWITCH
PASSENGER FRONT SIDE DOOR WINDOW SWITCH
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
SIG GND
VIO WIRE
W/ EXPRESS UP/DOWN
W/ VEHICLE COMMUNICATION
W/O EXPRESS UP/DOWN
W/O VEHICLE COMMUNICATION
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Anti-theft circuit, w/o passive keyless entry (3 of 3) -> W/ VEHICLE COMMUNICATION
Wiring diagram w/ vehicle communication (2 of 2)
B+ VOLT
BLK WIRE
BLK/WHT WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN/YEL WIRE
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LIN BUS 16
LOGIC
PASSENGER DOOR LOCK SWITCH
PASSENGER FRONT SIDE DOOR WINDOW SWITCH
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
SIG GND
VIO WIRE
W/ EXPRESS UP/DOWN
W/ VEHICLE COMMUNICATION
W/O EXPRESS UP/DOWN
W/O VEHICLE COMMUNICATION
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Power door locks circuit, w/o passive keyless entry (3 of 3) -> W/ VEHICLE COMMUNICATION
