GMC Canyon III (2022-2024) seat memory switch set sig Wiring diagram
This page shows the only wiring diagram for the component.seat memory switch set sig, which is found in the car GMC Canyon III (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat memory switch set sig (1 of 1)
AUTOSAR CAN BUS (+) 4 SERIAL DATA
BATT POSITIVE VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SEAT ADJUSTER ACTUATOR
DRIVER FRONT SEAT ADJUSTER MEMORY SWITCH
DRIVER FRONT SEAT ADJUSTER SWITCH
DRIVER FRONT SEAT RECLINER ACTUATOR
DRIVER FRONT SEAT TILT ADJUSTER ACTUATOR
DRIVER FRONT SEAT VERTICAL ADJUSTER ACTUATOR
DRIVER SEAT ADJUSTER MEMORY MODULE (UNDER FRONT OF DRIVER'S SEAT CUSHION)
DRIVER SEAT ADJUSTER MEMORY MODULE LIN BUS 2
DRIVER SEAT FRT VERT MTR DOWN CTRL
DRIVER SEAT FRT VERT MTR UP CTRL
DRIVER SEAT HORIZ MTR FWD CTRL
DRIVER SEAT HORIZ MTR REARWARD CTRL
DRIVER SEAT LF REAR HAPTIC MOVEMENT MTR CTRL
DRIVER SEAT REAR VERT MTR DOWN CTRL
DRIVER SEAT REAR VERT MTR UP CTRL
DRIVER SEAT RECLINE MTR FWD CTRL
DRIVER SEAT RECLINE MTR REARWARD CTRL
DRIVER SEAT RH REAR HAPTIC MOVEMENT MTR CTRL
EXIT
GRN WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
ILL
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT FRONT SEAT LANE DEPARTURE WARNING ACTUATOR
LOCK
MEMORY MIRRORS CIRCUIT
NCA WIRE
RED/BRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RIGHT FRONT SEAT LANE DEPARTURE WARNING ACTUATOR
SEAT MEMORY SWITCH SET SIG
SEAT MEMORY SWITCH SIG 1
SET-
UNLOCK
VIO/YEL WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> Driver"s memory seat circuit -> SEAT MEMORY SWITCH SET SIG
