GMC Canyon III (2022-2024) roof rail air bag disable sw sig Wiring diagram
This page shows the only wiring diagram for the component.roof rail air bag disable sw sig, which is found in the car GMC Canyon III (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram roof rail air bag disable sw sig (1 of 1)
AUTOSAR CAN BUS (-) 9 SER DATA
BATT POS VOLT
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/ORG WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DETECT OFF SWITCH
GRN WIRE
GRY/ORG WIRE
HAZARD WARNING SWITCH
LEFT AIR BAG FRONT END DISCRIMINATING SENSOR
LF IMPACT DISCRIMINATING SIG
LF IMPACT SENSOR LO REF
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
ORG/WHT WIRE
ORG/YEL WIRE
PASS AIR BAG OFF IND CTRL PASS INSTRUMENT PANEL AIR BAG STAGE 2 LO CTRL
PASS AIR BAG ON IND CTRL
PASS INSTRUMENT PANEL AIR BAG STAGE 1 HI CTRL
PASS INSTRUMENT PANEL AIR BAG STAGE 1 LO CTRL
PASS INSTRUMENT PANEL AIR BAG STAGE 2 HI CTRL
PASS SEAT BELT ANCHOR PRETENSIONER HI CTRL
PASS SEAT BELT ANCHOR PRETENSIONER LO CTRL
PASS SEAT BELT IND CTRL ROOF RAIL AIR BAG DISABLE IND CTRL
PASS SEAT BELT RETRACTOR PRETENSIONER HI CTRL
PASSENGER FRONT SEAT BELT RETRACTOR
RED/GRN WIRE
RESTRAINTS CONTROL MODULE (UNDER CENTER CONSOLE)
RF IMPACT DISCRIMINATING SIG
RF IMPACT SENSOR LO REF PASSENGER SEAT BELT RETRACTOR PRETENSIONER LO CTRL
RIGHT AIR BAG FRONT END DISCRIMINATING SENSOR
ROOF RAIL AIR BAG DISABLE SW LO REF
ROOF RAIL AIR BAG DISABLE SW SIG
RUN/CRANK IGNITION 1 VOLTAGE
SIG GND
STEERING AIR BAG WHEEL COIL
STEERING WHEEL AIR BAG
STRG WHEEL AIR BAG STAGE 1 LO CTRL
VIO/ORG WIRE
VIO/WHT WIRE
W/ ROLL OVER SENSING SWITCH
W/O ROLL OVER SENSING SWITCH
WHT/GRN WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> ROOF RAIL AIR BAG DISABLE SW SIG
