GMC Canyon III (2022-2024) rear vertical up Wiring diagram
This page shows the only wiring diagram for the component.rear vertical up, which is found in the car GMC Canyon III (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear vertical up (1 of 1)
BATT POS VOLT
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER FRONT SEAT ADJUSTER ACTUATOR
DRIVER FRONT SEAT ADJUSTER SWITCH
DRIVER FRONT SEAT RECLINE ACTUATOR
DRIVER FRONT SEAT TILT ADJUSTER ACTUATOR
DRIVER FRONT SEAT VERTICAL ADJUSTER ACTUATOR
FRONT VERTICAL DOWN
FRONT VERTICAL UP
FWD DN
GRN WIRE
GRY WIRE
HORIZONTAL RWD
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
REAR VERTICAL DOWN HORIZONTAL FWD
REAR VERTICAL UP
RECLINE FWD
RECLINE RWD
RED WIRE
RED/GRY WIRE
RWD
VIO WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> REAR VERTICAL UP
