GMC Canyon III (2022-2024) park lights Wiring diagrams
This page contains all the electrical diagrams for the component. park lights, in which he is found in the car GMC Canyon III (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
park lights wiring diagram (1 of 3)
BACKUP LAMP CTRL
BACKUP LAMPS CIRCUIT
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
CENTER HIGH MOUNTED STOP LAMP SPLY VOLT
CHEVROLET
EXTERIOR COURTESY LAMP CTRL
GMC
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/YEL WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT FRONT DRL CTRL
LEFT FRONT FOG LAMP CTRL
LEFT FRONT HEADLAMP
LEFT FRONT PARK LAMP CTRL 2
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP CTRL
LEFT HEADLAMP HIGH BEAM CTRL
LEFT HEADLAMP LED DRIVER MODULE
LEFT HEADLAMP LOW BEAM CTRL
LEFT PARKING, TURN SIGNAL LAMP BULB
LEFT REAR PARK LAMP CTRL
LEFT REAR STOP LAMP CTRL
LEFT REAR TRAILER STOP/TURN LAMP CTRL
LEFT REAR TURN SIGNAL LAMP CTRL 2
LIGHTING CONTROL MODULE (LEFT KICK PANEL)
PARK LIGHTS
REAR LICENSE PLATE LAMP CTRL I
REAR WINDOW WASHER RELAY CTRL
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT DRL CTRL
RIGHT FRONT TURN SIGNAL LAMP CTRL
RIGHT HEADLAMP HIGH BEAM CTRL
RIGHT HEADLAMP LOW BEAM CTRL
RIGHT PARK LAMP CTRL 2
RIGHT REAR PARK LAMP CTRL
RIGHT REAR STOP LAMP CTRL
RIGHT REAR TRAILER STOP/TURN LAMP CTRL
RIGHT REAR TURN SIGNAL LAMP CTRL 2
RUN/CRANK IGNITION 1 VOLTAGE
TRAILER TOW CIRCUIT
TURN SIGNAL LIGHTS
VIO/BLK WIRE
VIO/WHT WIRE
W/ LED HEADLAMPS
W/O LED HEADLAMPS
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
WHT/YEL WIRE
WINDSHIELD WIPER SWITCH HIGH SIGNAL
WIPER/ WASHER SYSTEM
YEL WIRE
YEL/BLU WIRE
Go to component -> Exterior lamps circuit (2 of 5) -> PARK LIGHTS
park lights wiring diagram (2 of 3)
BLK WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
CHEVROLET/ GMC
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
LEFT "C" PILLAR)
LEFT CARGO LAMP
NCA WIRE
PARK LIGHTS
RED/BRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT CARGO LAMP
RIGHT FRONT HEADLAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HEADLAMP LED DRIVER MODULE
RIGHT PARKING, TURN SIGNAL LAMP BULB
RIGHT REAR LICENSE PLATE LAMP
TURN SIGNAL LIGHTS
W/ LED HEADLAMPS
W/O LED HEADLAMPS
WHT/BLU WIRE
WHT/VIO WIRE
WHT/YEL WIRE
Go to component -> Exterior lamps circuit (3 of 5) -> PARK LIGHTS
park lights wiring diagram (3 of 3)
BLK WIRE
BLU/BLK WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
CHEVROLET
CHEVROLET/ GMC
ENGINE WIRING HARNESS JUNCTION BLOCK
FROM PARKING LAMP RELAY (DIAGRAM 1 OF 5)
GMC
GRY/BLU WIRE
GRY/YEL WIRE
HIGH MOUNT STOP LAMP RELAY
HOT AT ALL TIMES
LEFT REAR BODY STRUCTURE STOP LAMP
LEFT REAR BODY STRUCTURE STOP LAMP LED DRIVER MODULE
LEFT TAIL/STOP LAMP
LEFT TAIL/TURN SIGNAL LAMP
PARK LIGHTS
RIGHT REAR BODY STRUCTURE STOP LAMP
RIGHT REAR BODY STRUCTURE STOP LAMP LED DRIVER MODULE
RIGHT TAIL/STOP LAMP
RIGHT TAIL/TURN SIGNAL LAMP
STOP LIGHTS
TRAILER LAMP CONTROL MODULE
TURN SIGNAL LIGHTS
W/ TAIL, STOP LAMP
W/O TAIL, STOP LAMP
WHT/BLU WIRE
WHT/YEL WIRE
Go to component -> Exterior lamps circuit (4 of 5) -> PARK LIGHTS
