GMC Canyon III (2022-2024) low beam lamp Wiring diagrams
This page contains all the electrical diagrams for the component. low beam lamp, in which he is found in the car GMC Canyon III (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram low beam lamp (1 of 2)
AMBIENT LIGHT SENSOR SIG
AUTOSAR CAN BUS (-) 9 SERIAL DATA
AUTOSAR CAN BUS (-) 9 SERIAL DATA SIG GND
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
ENGINE WIRING HARNESS JUNCTION BLOCK
GRY/BLU WIRE
HEADLAMP SW FLASH SIG
HI BEAM SELECT SW HI BEAM SIG
HIGH BEAM LAMP
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT FRONT HEADLAMP
LEFT HEADLAMP LED DRIVER MODULE
LF DRL CTRL
LF FOG LAMP CTRL RH HEADLAMP HI BEAM CTRL
LH HEADLAMP HI BEAM CTRL
LH HEADLAMP LO BEAM CTRL
LIGHTING CONTROL MODULE (LEFT KICK PANEL)
LOW BEAM LAMP
RED/BRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RF DRL CTRL
RH HEADLAMP LO BEAM CTRL
SENSOR LOW REF
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Headlights circuit (1 of 2) -> LOW BEAM LAMP
Wiring diagram low beam lamp (2 of 2)
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BRN/GRY WIRE
FTP
HIGH BEAM LAMP
LEFT FRONT FOG LAMP
LOW BEAM LAMP
RED/YEL WIRE
RIGHT FRONT FOG LAMP
RIGHT FRONT HEADLAMP
RIGHT HEADLAMP LED DRIVER MODULE
SUNLOAD, AMBIENT LIGHT, SECURITY INDICATOR SENSOR
TURN SIGNAL SWITCH
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Headlights circuit (2 of 2) -> LOW BEAM LAMP
