GMC Canyon III (2022-2024) incremental encoder sens low ref Wiring diagram

AUTOSAR CAN BUS (+) 2 SERIAL DATA AUTOSAR CAN BUS (-) 2 SERIAL DATA ROTARY POSI SENS SIG BATT POS VOLT BATTERY DISTRIBUTION ENGINE COMPARTMENT FUSE BLOCK BLK WIRE BLU WIRE BLU/GRY WIRE BLU/YEL WIRE COMPUTER DATA LINES SYSTEM ENGINE WIRING HARNESS JUNCTION BLOCK FRONT AXLE ACTR CTRL FRONT DRIVE AXLE ACTUATOR FRONT DRIVE AXLE ACTUATOR RELAY GEAR POSI SENS LOW REF GRN WIRE GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES INCREMENTAL ENCODER DIR SIG INCREMENTAL ENCODER IMPULSE SIG INCREMENTAL ENCODER SENS LOW REF INCREMENTAL ENCODER SENS VOLT REF LOGIC MOTOR COUNTER CLOCKWISE CTRL RED/WHT WIRE RUN/CRANK IGN 1 VOLT SECONDARY AXLE MOTOR RELAY CTRL TRANSFER CASE CONTROL MODULE (UNDER AIR CLEANER ASSEMBLY) TRANSFER CASE LOCK SOLENOID CTRL 2 TRANSFER CASE LOCK SOLENOID LOW REF TRANSFER CASE LOCK SOLENOID VALVE CTRL TRANSFER CASE MOTOR CLOCKWISE CTRL TRANSFER CASE MOTOR LOW REF VIO WIRE VIO/BLK WIRE VIO/GRY WIRE W/ SINGLE SPEED, TWO SPEED ACTIVE TRANSFER CASE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/VIO WIRE YEL/WHT WIRE
