GMC Canyon III (2022-2024) front driver axle actuator relay Wiring diagram
This page shows the only wiring diagram for the component.front driver axle actuator relay, which is found in the car GMC Canyon III (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front driver axle actuator relay (1 of 1)
ACCESSORY AC, DC POWER CONTROL MODULE RELAY
ACCESSORY TIME DELAY CUTOFF RELAY
AIR CONDITIONING COMPRESSOR RELAY
BLK WIRE
BLK/WHT WIRE
BLUNT CUT)
BODY CONTROL MODULE
BRN/BLK WIRE
ENGINE CONTROLS IGNITION RELAY
ENGINE RESTART RELAY
FROM DC/AC CONVERTER CONTROL MODULE (DIAGRAM 5 OF 9)
FROM IGNITION MAIN RELAY (DIAGRAM 8 OF 9)
FRONT DRIVER AXLE ACTUATOR RELAY
FRONT FLOOR CONSOLE ACCESSORY POWER REAR RECEPTACLE
GRY/GRN WIRE
HIGH MOUNT STOP LAMP RELAY
HORN RELAY
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT TRAILER STOP/TURN SIGNAL LAMP RELAY
LOGIC
N/A
PARKING LAMP RELAY
REAR WINDOW DEFOGGER RELAY
RED/BRN WIRE
RED/VIO WIRE
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
STARTER RELAY
TO DC/AC CONVERTER CONTROL MODULE (DIAGRAM 5 OF 9)
TRAILER BACKUP LAMP RELAY
TRAILER BRAKE CONTROL MODULE
TRAILER BRAKE PROVISION
UNDERBODY CAMERA WASHER FLUID PUMP RELAY
VIO WIRE
W/O TRAILER PROVISIONS
WHT/GRN WIRE
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WIPER MOTOR RELAY
WINDSHIELD WIPER MOTOR SPEED CONTROL RELAY
Go to component -> Power distribution circuit (2 of 9) -> FRONT DRIVER AXLE ACTUATOR RELAY
