GMC Canyon III (2022-2024) distance sensing cruise ctrl gap up/down switch sig Wiring diagram
This page shows the only wiring diagram for the component.distance sensing cruise ctrl gap up/down switch sig, which is found in the car GMC Canyon III (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram distance sensing cruise ctrl gap up/down switch sig (1 of 1)
AUTOSAR CAN BUS (-) 9 SERIAL DATA
BATT POS VOLT
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
CRUISE CONTROL SYSTEM
DISTANCE SENSING CRUISE CTRL GAP UP/DOWN SWITCH SIG
ENGINE WIRING HARNESS JUNCTION BLOCK
FORWARD COLLISION ALERT SWITCH
GRY/GRN WIRE
GRY/WHT WIRE
HAZARD WARNING SWITCH
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LANE DEPARTURE WARNING DISABLE SWITCH
LANE DEPARTURE WARNING DISABLE SWITCH SIG
LANE DEPARTURE WARNING IND
LANE DEPARTURE WARNING INDICATOR CTRL
LANE DEPARTURE WARNING SWITCH
RED/GRY WIRE
STEERING WHEEL AIR BAG COIL
STEERING WHEEL RESISTOR LADDER LOW REF
VIO/BLK WIRE
VIO/WHT WIRE
W/ ADAPTIVE CRUISE CONTROL
WHT WIRE
WHT/GRN WIRE
Go to component -> Lane departure warning circuit (2 of 2) -> DISTANCE SENSING CRUISE CTRL GAP UP/DOWN SWITCH SIG
