GMC Canyon II facelift (2020-2022) w/ dual reading lamp Wiring diagram
This page shows the only wiring diagram for the component.w/ dual reading lamp, which is found in the car GMC Canyon II facelift (2020-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ dual reading lamp (1 of 1)
AJAR SW SIG
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN/WHT WIRE
CARGO LP SW SIG
COIL CONTROL
COMPUTER DATA LINES SYSTEM
COURTESY LP SW SIG
DOME LAMP
DRIVER DOOR LATCH ASSEMBLY
DRIVER WINDOW MOTOR
GMLAN SERIAL DATA
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
INTERIOR LP CONTROL
INTERIOR LP DEFEAT SW SIG
LF DR AJAR
LIN BUS 3
LOGIC
LP RELAY CONTROL
LT BLU WIRE
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER WINDOW SWITCH
PWR CONTROL
RED/VIO WIRE
RED/WHT WIRE
RF DR
SW SIG
VIO/WHT WIRE
W/ DUAL READING LAMP
W/O DUAL READING LAMP
WHT WIRE
WHT/BRN WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> W/ DUAL READING LAMP
