GMC Canyon II facelift (2020-2022) rr axle diff lock ind ctrl Wiring diagram
This page shows the only wiring diagram for the component.rr axle diff lock ind ctrl, which is found in the car GMC Canyon II facelift (2020-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr axle diff lock ind ctrl (1 of 1)
2.8L TURBO DIESEL
3.6L
AUXILIARY CHASSIS CONTROL MODULE (ABOVE SPARE TIRE)
AXLE DIFF LOCK MODE
AXLE DIFF LOCK SW SIG
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
DIFFERENTIAL LOCK SWITCH
DISPLAY
DRIVER INFORMATION CENTER DISPLAY
GMLAN SERIAL DATA 2
GRY/BLK WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
LOGIC
REAR DIFFERENTIAL LOCK ACTUATOR
REAR DIFFERENTIAL LOCK ACTUATOR HIGH CONTROL RELAY
REAR DIFFERENTIAL LOCK ACTUATOR LOW CONTROL RELAY
RR AXLE DIFF LOCK CTRL
RR AXLE DIFF LOCK IND CTRL
RR AXLE DIFF LOCK LOW REF
RUN/CRANK IGN 1 VOLTAGE
UNDERHOOD FUSE BLOCK
VIO/BLK WIRE
VIO/BRN WIRE
VIO/GRY WIRE
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Rear differential lock circuit -> RR AXLE DIFF LOCK IND CTRL
