GMC Canyon II facelift (2020-2022) lr otr park ass sens sig Wiring diagram
This page shows the only wiring diagram for the component.lr otr park ass sens sig, which is found in the car GMC Canyon II facelift (2020-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lr otr park ass sens sig (1 of 1)
3.6L 2.5L 2.8L TURBO DIESEL
BATT POS VOLT
BLK WIRE
BLK/GRY WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DISABLE SIG
DISPLAY
GMLAN SERIAL DATA
GRN WIRE
GRN/BRN WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
LED DISABLE SIG
LEFT REAR MIDDLE PARKING ASSIST SENSOR
LEFT REAR OUTER PARKING ASSIST SENSOR
LO SPD GMLAN SERIAL DATA 2
LOGIC
LR MIDDLE PARK SENS SIG
LR OTR PARK ASS SENS SIG
OBJ SENS LOW REF
OBJ SENS SPLY VOLT
PARKING ASSIST CONTROL MODULE
REAR PARK ASSIST DISABLE SWITCH
REAR PARKING ASSIST DISABLE IND
RED/GRN WIRE
RIGHT REAR MIDDLE PARKING ASSIST SENSOR
RIGHT REAR OUTER PARKING ASSIST SENSOR
RR MIDDLE PARK ASS SENS SIG
RR OTR PARK ASS SENS SIG
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit -> LR OTR PARK ASS SENS SIG
