GMC Canyon II facelift (2020-2022) left trailer turn sig lamp Wiring diagram
This page shows the only wiring diagram for the component.left trailer turn sig lamp, which is found in the car GMC Canyon II facelift (2020-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left trailer turn sig lamp (1 of 1)
AUX CTRL
BACKUP LAMP RELAY CONTROL
BACKUP LAMPS CIRCUIT
BATTERY FUSE BLOCK
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GMLAN SERIAL DATA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT TRAILER STOP/TURN SIGNAL LAMP RELAY
LEFT TRAILER TURN SIG LAMP
ORG/ WIRE
PARK LAMP RELAY CONTROL
RED WIRE
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
RIGHT TRAILER TURN SIG LAMP
TRAILER BACKUP LAMPS RELAY
TRAILER BRAKE APPLY SIG
TRAILER BRAKE POWER CONTROL MODULE
TRAILER BRAKE PROVISION (BLUNT CUT)
TRAILER CONNECTOR
TRAILER PARK LAMPS RELAY
TRAILER PROVISION (BLUNT CUT)
TRAILER)
UNDERHOOD FUSE BLOCK
W/ TRAILER CONNECTOR
W/O INTEGRATED TRAILER BRAKE
W/O TRAILER CONNECTOR
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Trailer tow circuit -> LEFT TRAILER TURN SIG LAMP
