GMC Canyon II facelift (2020-2022) generator field duty cycle sig Wiring diagrams
This page contains all the electrical diagrams for the component. generator field duty cycle sig, in which he is found in the car GMC Canyon II facelift (2020-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram generator field duty cycle sig (1 of 2)
2.5L
2.8L TURBO DIESEL
225 (OR 25)
3.6L
BATTERY
BATTERY CURRENT SENSOR (NEGATIVE BATTERY CABLE)
BATTERY FUSE BLOCK
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
CHARGE IND
COMPUTER DATA LINES SYSTEM
CURRENT SENSOR SIG
CURRENT SENSOR SUPPLY VOLTAGE
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE (UNDER COOLANT RESERVOIR)
GENERATOR
GENERATOR FIELD DUTY CYCLE SIG
GENERATOR TURN ON SIG
GROUND
GRY WIRE
GRY/GRN WIRE
HIGH SPEED GMLAN SERIAL DATA (-) (1)
INSTRUMENT CLUSTER
LOGIC
LOW REF
LOW SPD GMLAN SERIAL DATA
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/YEL WIRE
Go to component -> Charging circuit -> GENERATOR FIELD DUTY CYCLE SIG
Wiring diagram generator field duty cycle sig (2 of 2)
BLK/BRN WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CHARGE INDICATOR CTRL
COOLANT TEMP SENS LOW REF
COOLER INLET TEMP SENS SIG
COOLER OUTLET TEMP SENS SIG
COOLING FAN SPEED LOW REF
COOLING FANS SYSTEM
ENGINE CONTROL MODULE (UNDER COOLANT RESERVOIR)
ENGINE COOLANT TEMP SENS SIG
EXHAUST GAS RECIRCULATION VALVE
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3
FUEL INJECTOR 4
FUEL RAIL PRESS SENS 2 SIG
FUEL RAIL PRESS SENS LOW REF
FUEL RAIL PRESSURE SENSOR
GENERATOR FIELD DUTY CYCLE SIG
GLOW PLUG 1
GLOW PLUG 2
GLOW PLUG 3
GLOW PLUG 4
GLOW PLUG CTRL 1
GLOW PLUG CTRL 2
GLOW PLUG CTRL 3
GLOW PLUG CTRL 4
GRN WIRE
GRN/GRY WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
INDUCTION AIR TEMP SENS 2 SIG
INJECTOR HIGH CTRL
INLET TEMP SENS LOW REF
OIL PRESS SENS LOW REF
OIL PRESS SENS SIG
OUTLET TEMP SENS LOW REF
POS INTAKE SENS 1
POS INTAKE SENS CTRL 1
POS INTAKE SENS LOW REF 1
RECIRCULATION SENS LOW REF
RECIRCULATION VALVE MTR HIGH SIG
RECIRCULATION VALVE MTR LOW SIG
RECIRCULATION VALVE SENS SIG
SENS FUEL TEMP 1 LOW REF
SENS FUEL TEMP 1 SIG
STARTING/CHARGING SYSTEM
THROTTLE POS SENS LOW REF
VIO/BLK WIRE
VOLT CTRL CYLINDER 1
VOLT CTRL CYLINDER 2
VOLT CTRL CYLINDER 3
VOLT CTRL CYLINDER 4
VOLT SPLY CYLINDER 1
VOLT SPLY CYLINDER 2
VOLT SPLY CYLINDER 3
VOLT SPLY CYLINDER 4
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.8l vin 1 (8 of 8) -> GENERATOR FIELD DUTY CYCLE SIG
