GMC Canyon II facelift (2020-2022) cooling fan spd sig ctrl rly spd sig Wiring diagrams

This page contains all the electrical diagrams for the component. cooling fan spd sig ctrl rly spd sig, in which he is found in the car GMC Canyon II facelift (2020-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram cooling fan spd sig ctrl rly spd sig (1 of 3)

Wiring diagram cooling fan spd sig ctrl rly spd sig for GMC Canyon II facelift (2020-2022) (1 of 3)

Get access

2.5L 2.5L 3.6L 2.5L, 2.8L TURBO DIESEL 2.8L TURBO DIESEL 2.8L TURBO DIESEL 3.6L 2.5L 3.6L A/C PRESS SENS 5 VOLT REF A/C REFRIGERANT PRESS SENS SIG A/C REFRIGERANT PRESSURE SENSOR AIR TEMP SENS SIG COOLANT TEMP SENS SIG 2 AMBIENT AIR TEMPERATURE SENSOR BATT POS VOLT BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BLU/VIO WIRE BRN/RED WIRE COMPRESSOR CLUTCH COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR (2.5L, 3.6L) (BEHIND RADIATOR) COOLING FAN RELAY COOLING FAN SPD LOW REF COOLING FAN SPD SIG CTRL RLY SPD SIG ENG COOLANT TEMP SENS SIG ENGINE CONTROL MODULE (UNDER COOLANT RESERVOIR) ENGINE COOL CTRL ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT THERMOSTAT HEATER GRN WIRE GRY/RED WIRE HI SPD GMLAN SERIAL DATA (-) (1) HOT AT ALL TIMES HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED J108 (2.5L) J135 (3.6L) J112 (2.5L) LO REF LOGIC LOW REF RADIATOR COOLANT TEMPERATURE SENSOR RED/GRY WIRE RED/WHT WIRE RLY CTRL BATT POSITIVE VOLT COOLING FAN CTRL RLY SPD SIG RLY SPD SIG UNDERHOOD FUSE BLOCK VIO/BLU WIRE WHT WIRE WHT/BLK WIRE WHT/GRY WIRE YEL/BLK WIRE

Go to component -> Automatic a/c circuit (4 of 4) -> COOLING FAN SPD SIG CTRL RLY SPD SIG

Wiring diagram cooling fan spd sig ctrl rly spd sig (2 of 3)

Wiring diagram cooling fan spd sig ctrl rly spd sig for GMC Canyon II facelift (2020-2022) (2 of 3)

Get access

2.5L 2.5L, 2.8L TURBO DIESEL 2.8L TURBO DIESEL 2.8L TURBO DIESEL 3.6L 2.5L 3.6L BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/VIO WIRE COMPUTER DATA LINES SYSTEM COOLANT TEMP SENS SIG 2 COOLING FAN RELAY COOLING FAN SPD LOW REF COOLING FAN SPD SIG CTRL RLY SPD SIG ENG COOLANT TEMP SENS SIG ENGINE CONTROL MODULE (UNDER COOLANT RESERVOIR) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR GRY WIRE GRY/RED WIRE HI SPD GMLAN SERIAL DATA (-) (1) HOT AT ALL TIMES HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED J112 (2.5L) LO REF LOGIC RADIATOR COOLANT TEMPERATURE SENSOR RED/WHT WIRE RLY CTRL BATT POSITIVE VOLT COOLING FAN CTRL RLY SPD SIG UNDERHOOD FUSE BLOCK WHT WIRE WHT/BLK WIRE YEL/BLK WIRE

Go to component -> Cooling fan circuit (1 of 2) -> COOLING FAN SPD SIG CTRL RLY SPD SIG
