GMC Canyon II facelift (2020-2022) audio low ref Wiring diagrams

This page contains all the electrical diagrams for the component. audio low ref, in which he is found in the car GMC Canyon II facelift (2020-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram audio low ref (1 of 4)

Wiring diagram audio low ref for GMC Canyon II facelift (2020-2022) (1 of 4)

Get access

AUDIO LOW REF AUDIO SIG + BATT POS VOLT BLK/GRY WIRE BLK/WHT WIRE BLU/BLK WIRE COAX COAX BK AM/FM COAX BK XM DISPLAY DISPLAY SIGNAL (-) GRY/YEL WIRE HOT AT ALL TIMES INFO DISPLAY MODULE INSTRUMENT PANEL FUSE BLOCK LOGIC LVDS LVDS BK NAVIGATION DISPLAY SIGNAL MICROPHONE (-) LOW REF MICROPHONE SIG NAVIGATION NCA WIRE RADIO RADIO CONTROLS RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MOBILE TELEPHONE MICROPHONE USB USB BK VIO/YEL WIRE

Go to component -> Navigation circuit, w/ amplifier (1 of 4) -> AUDIO LOW REF

Wiring diagram audio low ref (2 of 4)

Wiring diagram audio low ref for GMC Canyon II facelift (2020-2022) (2 of 4)

Get access

AUDIO LOW REF AUDIO SIG + BATT POS VOLT BLK/GRY WIRE BLK/WHT WIRE BLU/BLK WIRE COAX COAX BK AM/FM COAX BK XM DISPLAY DISPLAY SIGNAL (-) GRN/BLK WIRE GRY/YEL WIRE HOT AT ALL TIMES INFO DISPLAY MODULE INSTRUMENT PANEL FUSE BLOCK LOGIC LR SPEAKER SIG (-) LVDS LVDS BK NAVIGATION DISPLAY SIGNAL MICROPHONE (-) LOW REF MICROPHONE SIG NAVIGATION NCA WIRE RADIO RADIO CONTROLS RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MOBILE TELEPHONE MICROPHONE USB USB BK USB SERIAL DATA VIO/YEL WIRE

Go to component -> Navigation circuit, w/o amplifier (1 of 4) -> AUDIO LOW REF

Wiring diagram audio low ref (3 of 4)

Wiring diagram audio low ref for GMC Canyon II facelift (2020-2022) (3 of 4)

Get access

AUDIO LOW REF AUDIO SIG + BATT POS VOLT BK COAX AM/FM BK COAX XM BK LVDS NAVIGATION DISPLAY SIGNAL BK USB BLK/GRY WIRE BLK/WHT WIRE BLU/BLK WIRE COAX DISPLAY DISPLAY SIGNAL (-) GRY/YEL WIRE HOT AT ALL TIMES INFO DISPLAY MODULE INSTRUMENT PANEL FUSE BLOCK LOGIC LVDS MICROPHONE (-) LOW REF MICROPHONE SIG NAVIGATION NCA WIRE RADIO RADIO CONTROLS RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MOBILE TELEPHONE MICROPHONE USB VIO/YEL WIRE

Go to component -> Radio circuit, mid/high level w/ amplifier (1 of 4) -> AUDIO LOW REF

Wiring diagram audio low ref (4 of 4)

Wiring diagram audio low ref for GMC Canyon II facelift (2020-2022) (4 of 4)

Get access

AUDIO LOW REF AUDIO SIG + BATT POS VOLT BK COAX AM/FM BK COAX XM BK LVDS NAVIGATION DISPLAY SIGNAL BK USB USB SERIAL DATA BLK/GRY WIRE BLK/WHT WIRE BLU/BLK WIRE COAX DISPLAY DISPLAY SIGNAL (-) GRN/BLK WIRE GRY/YEL WIRE HOT AT ALL TIMES INFO DISPLAY MODULE INSTRUMENT PANEL FUSE BLOCK LOGIC LR SPEAKER SIG (-) LVDS MICROPHONE (-) LOW REF MICROPHONE SIG NAVIGATION NCA WIRE RADIO RADIO CONTROLS RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MOBILE TELEPHONE MICROPHONE USB VIO/YEL WIRE

Go to component -> Radio circuit, mid/high level w/o amplifier (1 of 4) -> AUDIO LOW REF

GMC Canyon II facelift (2020-2022) audio low ref Wiring diagrams

Wiring diagram audio low ref (1 of 4)

List of components:

Wiring diagram audio low ref (2 of 4)

List of components:

Wiring diagram audio low ref (3 of 4)

List of components:

Wiring diagram audio low ref (4 of 4)

List of components:
