GMC Cab & Chassis Sierra 3500 (2004-2007) steering column fuse holder Wiring diagram
This page shows the only wiring diagram for the component.steering column fuse holder, which is found in the car GMC Cab & Chassis Sierra 3500 (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column fuse holder (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DK GRN/WHT WIRE
EXCEPT 10 SERIES OR CREW CAB
GARAGE DOOR OPENER OVERHEAD CONSOLE
HEADLIGHTS SYSTEM
HVAC CONTROL MODULE
INFLATABLE RESTRAINT I/P MODULE DISABLE SWITCH
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LOGIC
LOWER RIGHT
NCA WIRE
POWER TAKE OFF (PTO) SWITCH OR AUXILIARY POWER OUTLET SWITCH (HYBRID)
PPL/WHT WIRE
REMOTE PLAYBACK DEVICE (CD PLAYER)
STEERING COLUMN FUSE HOLDER
STEERING WHEEL)
TRACTION CONTROL SWITCH
TRANSFER CASE SHIFT CONTROL SWITCH
UPPER LEFT
UPPER RIGHT
WHT WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> STEERING COLUMN FUSE HOLDER
