GMC Cab & Chassis Sierra 3500 (2004-2007) pnk Wiring diagrams

This page contains all the electrical diagrams for the component. pnk, in which he is found in the car GMC Cab & Chassis Sierra 3500 (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram pnk (121 of 124)

Wiring diagram pnk for GMC Cab & Chassis Sierra 3500 (2004-2007) (121 of 124)

Get access

BLK WIRE BLK/WHT WIRE BRN WIRE DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (ON LEFT SIDE OF INNER FRAME) FRONT AXLE ACTUATOR (ON FRONT AXLE) FUSE GAS (PCM) DIESEL (ECM) GRY WIRE GRY/BLK WIRE HOT IN HOT IN RUN OR START I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH) IGN E FUSE INSTRUMENT PANEL CLUSTER LAMP LOGIC LT BLU WIRE MODULE (DIESEL) (LEFT FRONT OF ENGINE COMPT) PNK WIRE POWERTRAIN CONTROL MODULE (GAS ENGINES) OR ENGINE CONTROL PPL 2 RUN WIRE SEO IGN FUSE SPLICE PACK TRANSFER CASE SHIFT CONTROL SWITCH (ON TOP OF TRANSFER CASE) TRANSMISSION CONTROL MODULE (W/ ALLISON TRANS) (LEFT FRONT OF ENGINE COMPT) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)

Go to component -> 6.6l vin d, transfer case circuit, 2-speed manual -> PNK WIRE

Wiring diagram pnk (122 of 124)

Wiring diagram pnk for GMC Cab & Chassis Sierra 3500 (2004-2007) (122 of 124)

Get access

2-HI IND 4 HI 4 LO 4-HI IND 4-LO IND 4-LO IND 4-HI IND AXLE SW SIG BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE CLASS II DATA AXLE CTRL CONTROL MODULE DIESEL: ENGINE CONTROL MODULE CTRL DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DIESEL (ECM) DK GRN WIRE DK GRN/WHT WIRE ENCODER ENCODER LOW GROUND ENCODER SIG FRONT AXLE ACTUATOR (ON FRONT AXLE) FT SHAFT LO FT SHAFT HI FUSE GAS (PCM) GROUND BATTERY MOTOR CTRL A MOTOR CTRL B GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR START I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH) I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH) SEO IGN FUSE I/P RELAY BLOCK (UNDER LEFT SIDE OF DASH) IGN E FUSE ILLUMINATION INSTRUMENT PANEL CLUSTER LAMP LOCK SOL CTRL 2-HI IND NEUTRAL IND LOGIC LT BLU WIRE LT GRN/BLK WIRE NEUTRAL IND ORG/ WIRE PNK WIRE PPL PPL/WHT WIRE RED WIRE RR SHAFT HI RR SHAFT LO RUN WIRE SHIFT MOTOR SPLICE PACK TAN/BLK WIRE TRANSFER CASE ENCODER MOTOR (LEFT SIDE OF TRANSFER CASE) TRANSFER CASE SHIFT CONTROL MODULE (BEHIND HEADLAMP SWITCH) TRANSFER CASE SHIFT CONTROL SWITCH TRANSMISSION SYSTEM TREC FUSE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)

Go to component -> 6.6l vin d, transfer case circuit, selectable -> PNK WIRE
