4.3l (vin z), transmission circuit, 4l60-e for GMC Cab & Chassis K3500 (1985-2000)

1-2 SHIFT SOL 2-3 SHIFT SOL 3-2 SHIFT SOL BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P) DK BLU WIRE ECM IGN FUSE ELECTRONIC 4-SPEED AUTOMATIC OVERDRIVE TRANSMISSION ENGINE COOLANT TEMPERATURE (ECT) SENSOR (TOP FRONT OF ENGINE) FUSIBLE LINK GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START HOT IN START OR RUN FUSE BLOCK TRANS FUSE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE POWERTRAIN CONTROL MODULE (PCM) (UNDER RIGHT END OF I/P) PPL PPL/WHT WIRE PRESSURE CONTROL SOLENOID RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SPEED SENSOR (LEFT REAR SIDE OF TRANSMISSION) TAN/BLK WIRE TCC SOL TCC/BRAKE SWITCH (TOP OF BRAKE PEDAL) THROTTLE POSITION SENSOR (RIGHT SIDE OF TBI) TRANS FLUID TEMP (TFT) SENSOR VEHICLE SPEED SENSOR BUFFER (UNDER RIGHT END OF I/P) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
