Instrument cluster circuit, diesel for GMC Cab & Chassis K3500 (1985-2000)

A/T ACCY AIR BAG ANTI-LOCK BRAKES ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/WHT WIRE BRAKE PRESSURE WARNING SWITCH (ON REAR OF BRAKE PRESSURE MODULATOR VALVE BODY) BRAKE/ BRN WIRE BRN/WHT WIRE BULB TEST CHECK GAUGES CHECK GAUGES LAMP DRIVER CONVENIENCE CENTER (BEHIND LEFT SIDE OF I/P) DAYTIME RUNNING LAMPS DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ELECTRONIC PRNDL DISPLAY MODULE ENG-I MINI FUSE ENGINE CONTROLS SYSTEM ENGINE CONTROLS SYSTEM SOUND SYSTEMS ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENDER (FRONT OF LEFT CYLINDER HEAD) FUEL GAUGE FUEL PUMP, SENDER (IN FUEL TANK) GAUGES FUSE 4 GEN WAIT TO GRY WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM (DRL) HI BEAM HOT IN RUN OR START I/P FUSE BLOCK (BEHIND LEFT SIDE OF I/P) IGNITION SWITCH ILLUM INSTRUMENT CLUSTER LEFT TURN LOCK OFF W/ DRL ONLY LOW COOLANT LOW COOLANT LEVEL SENDER (IN COOLANT RESERVOIR) LOW ENGINE COOLANT LEVEL INDICATOR MODULE (UNDER CENTER OF I/P) LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE M/T PNK WIRE NCA WIRE OIL PRESS OIL PRESSURE SWITCH/SENDER (LEFT REAR TOP OF ENGINE) PARK BRAKE WARNING SWITCH (LEFT END OF I/P) PNK WIRE PPL PPL/WHT WIRE RIGHT TURN RUN WIRE SAFETY BELT SERVICE ENGINE SOON SERVICE THROTTLE SOON UP- SHIFT SPEED- OMETER STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TACH VOLT- METER TAN WIRE TAN/ WHT WIRE TAN/BLK WIRE TAN/WHT WIRE TEMP GAUGE TRANS FUSE 20 TRANSMISSSION RANGE SELECTOR TRUNK, TAILGATE, FUEL DOORS SYSTEM TRUNK/TAIL- GATE/FUEL DOORS SYSTEM UNDERHOOD FUSE/RELAY CENTER (LEFT REAR OF ENGINE COMPT) VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION) VEHICLE SPEED SENSOR BUFFER (BEHIND RIGHT END OF I/P) W/O DRL ONLY WARNING SYSTEMS WATER IN FUEL WATER-IN FUEL SENSOR (TOP REAR OF ENGINE) WHT TAN/ WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
