GMC Cab & Chassis K2500 (1989-2000) Headlamps circuit, drl with sealed beam lamps

BLK WIRE BRN WIRE BULB CHECK DAYTIME RUNNING LAMP INDICATOR DAYTIME RUNNING LAMPS MODULE (BEHIND LEFT SIDE OF I/P) DAYTIME RUNNING LAMPS RELAY (ENGINE COMPARTMENT FRONT PLENUM PANEL) DK BLU/WHT WIRE DRL FUSE FUSE BLOCK GRN WIRE HEAD PARK HEADLAMP DIMMER SWITCH HEADLIGHT SWITCH ASSEMBLY HI BEAM INDICATOR HI LO HOT AT ALL TIMES HOT IN RUN HOT IN RUN, BULB TEST OR START GAUGES FUSE HTR A/C FUSE IGNITION LAMP FEED HI BEAM FEED HI BEAM INDICATOR OUTPUT TO RELAY GROUND INSTRUMENT CLUSTER LEFT HEADLAMP ASSEMBLY LT GRN WIRE LT GRN/BLK WIRE LT LT OFF OFF HEAD ORG/ WIRE PARK PARK BRAKE WARNING SWITCH (AT PARK BRAKE, UNDER LEFT SIDE OF I/P) PICKUP ONLY PNK/BLK WIRE RIGHT HEADLAMP ASSEMBLY SUBURBAN, UTILITY ONLY TAN WIRE TAN/WHT WIRE WHT WIRE YEL WIRE
