6.5l (vin p), transmission circuit for GMC Cab & Chassis C2500 (1989-2000)

1-2 SHIFT SOL 2-3 SHIFT SOL 3-2 SHIFT SOL TRANS FLUID TEMP (TFT) SENSOR 999 998 961 452 389 995 PPL ACCELERATOR PEDAL POSITION (APP) MODULE (TOP OF ACCEL- ERATOR BRACKET) APP #3 APP #3 SENSOR SIG APP 1 APP 2 BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE ECM I FUSE ECM-B FUSE ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LEFT LOWER FRONT OF ENGINE BLOCK) GAUGES FUSE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK INSTRUMENT CLUSTER LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE PNK IGNITION FEED 3-2 CONTROL SOL DIAGNOSTIC REQUEST WIRE PNK WIRE POWERTRAIN CONTROL MODULE (UNDER RIGHT SIDE OF DASH) PPL PPL TCC/BRAKE SW PPL/WHT WIRE PRESSURE CONTROL SOLENOID RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SERVICE ENGINE SOON SPEED SENSOR (LEFT REAR SIDE OF TRANSMISSION) STOP/HAZ FUSE 1 TAN WIRE TAN/BLK WIRE TCC PWM SOL TCC SOL TCC/STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) TRANS FUSE 20 TRANSFER CASE SWITCH TRANSMISSION UNDERHOOD FUSE/RELAY CENTER VEHICLE SPEED SENSOR BUFFER (UNDER RIGHT END OF DASH) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
