6.5l (vin f), anti-lock brake circuits for GMC C3500 HD (1991-2000)

ABS FUSE ABS IND. BATTERY PUMP MOTOR GROUND BLK WIRE BLK/WHT WIRE BRAKE FUSE 18 BRAKE IND BRAKE PRESSURE WARNING SWITCH (UNDERSIDE OF EBCM) BRN WIRE DAYTIME RUNNING LAMP (DRL) MODULE (BEHIND LEFT SIDE OF DASH) DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROLS SYSTEM FRONT AXLE ACTUATOR (ON RIGHT REAR OF FRONT DRIVE AXLE) FUSE/RELAY BLOCK (LEFT REAR OF ENGINE COMPT) GAUGES FUSE 4 HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START I/P FUSE BLOCK (UNDER LEFT SIDE OF DASH) IGNITION ABS IND GROUND BRAKE SW INPUT INSTRUMENT CLUSTER LEFT FRONT WHEEL SPEED SENSOR LT BLU WIRE LT GRN WIRE M/T NEAR BREAKOUT TO TRANSFER CASE RELAY) PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT SIDE OF DASH) PPL PPL DATA LINK CONNECTOR (DLC) (LEFT OF STEERING COLUMN) PPL PPL 1807 680 PPL SERIAL DATA RED WIRE RIGHT FRONT WHEEL SPEED SENSOR SENSOR LOW SENSOR LOW SENSOR HIGH SENSOR HIGH 830 872 SERIAL DATA STOPLAMP SWITCH (TOP OF BRAKE PEDAL) TAN WIRE TAN/WHT WIRE TRANSFER CASE CONTROL MODULE (ON STEERING COLUMN SUPPORT BRACKET) TRANSMISSIONS SYSTEM VSS OUT VSS SIG BRAKE LAMP IND OUT SERIAL DATA LINE BRAKE IND INPUT EBCM GROUND YEL WIRE YEL/BLK WIRE
