Car Wiring Diagrams for Front wiper/washer circuit for GMC Acadia II facelift (2019-2024)

BATT POS VOLT BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (UNDER CENTER OF DASH) BRN/GRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM DELAY SWITCH DRIVER INFORMATION CENTER DISPLAY FRONT WINDSHIELD WIPER SW HIGH SIG GRN/BRN WIRE GRY WIRE GRY/GRN WIRE GRY/VIO WIRE HIGH SPD GMLAN SERIAL DATA (+) 1 HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK INT LOW OFF HIGH INT OFF LOW MIST HIGH LOGIC LOW SPEED GMLAN SER DATA 2 LOW WASHER FLUID IND CTRL MIST RAIN SENSOR REAR BODY FUSE BLOCK RED/BLU WIRE RED/WHT WIRE SIG GND UNDERHOOD FUSE BLOCK VIO WIRE WASHER SWITCH WHT WIRE WHT/BLK WIRE WHT/VIO WIRE WINDSHIELD WASHER FLUID LEVEL SWITCH WINDSHIELD WASHER PUMP WINDSHIELD WASHER PUMP RELAY WINDSHIELD WASHER RLY CTRL WINDSHIELD WASHER SW SIG WINDSHIELD WIPER MOTOR WINDSHIELD WIPER MOTOR PARK SW SIG WINDSHIELD WIPER MOTOR RLY COIL CTRL WINDSHIELD WIPER RELAY WINDSHIELD WIPER SPEED CONTROL RELAY WINDSHIELD WIPER SW HIGH SIG WINDSHIELD WIPER SW LOW REF WINDSHIELD WIPER SW LOW SIG WINDSHIELD WIPER/WASHER SWITCH WIPER SWITCH YEL/BLU WIRE YEL/BRN WIRE
