GMC Acadia II facelift (2019-2024) mirror low ref mirror sig Wiring diagram
This page shows the only wiring diagram for the component.mirror low ref mirror sig, which is found in the car GMC Acadia II facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror low ref mirror sig (1 of 1)
BACKUP LP CTRL RUN/CRANK IGN 1 VOLT
BK COAX
BLK/WHT WIRE
BLK/YEL WIRE
COAX
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR- VIEW MIRROR
GRN/WHT WIRE
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSIDE REAR VIEW MIRROR
LOGIC
MIRROR DIMMING
MIRROR LOW REF MIRROR SIG
REAR VIEW CAMERA
UNDERHOOD FUSE BLOCK
VIDEO SIG
VIO/WHT WIRE
YEL/WHT WIRE
Go to component -> Electrochromic mirror circuit -> MIRROR LOW REF MIRROR SIG
