GMC Acadia II facelift (2019-2024) active grille air shutter 1 actuator Wiring diagram
This page shows the only wiring diagram for the component.active grille air shutter 1 actuator, which is found in the car GMC Acadia II facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram active grille air shutter 1 actuator (1 of 1)
ACTIVE GRILLE AIR SHUTTER 1 ACTUATOR
BLK WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
GRN/VIO WIRE
GRY/GRN WIRE
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN
INSTRUMENT CLUSTER
LIN BUS 1
LO SPD GMLSN SERIAL DATA 2
LOGIC
UNDERHOOD FUSE BLOCK
VIO/BLU WIRE
VIO/GRY WIRE
Go to component -> Active bodyworks circuit -> ACTIVE GRILLE AIR SHUTTER 1 ACTUATOR
