Video system circuit, with spo accessory for GMC Acadia I facelift (2013-2016)
Video system circuit, with spo accessory
2 1 FM ANT FM ANT
3 2 1 ACC VOLT
6 5 4 3 2 1 IGN VOLT GND L AUDIO (+) R AUDIO (+) VIDEO SIG (+) VIDEO SIG (-)
6 5 4 3 2 1 SERIAL DATA CLK L AUDIO (+) R AUDIO (+) VIDEO SIG (+) VIDEO SIG (-)
ANTENNA
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH)
CLK L AUDIO (+) R AUDIO (+) VIDEO SIG (+) VIDEO SIG (-)
DRIVER SEAT HEADREST VIDEO DISPLAY
DVD CONTROL MODULE
DVD RELAY
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
IGN VOLT
INFOTMNT FUSE
PASSENGER SEAT HEADREST VIDEO DISPLAY
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
VIDEO DISPLAY FUSE HOLDER
WHT WIRE
YEL WIRE
