Car Wiring Diagrams for Passenger power seat circuit for GMC Acadia I facelift (2013-2016)

2 WAY 8 WAY BLK WIRE DK BLU WIRE DK GRN WIRE DOWN HOT AT ALL TIMES I/P FUSE BLOCK I/P FUSE BLOCK (BEHIND RIGHT END OF DASH) LT BLU WIRE LT GRN WIRE PASSENGER SEAT ADJUSTER SWITCH PASSENGER SEAT FRONT VERTICAL MOTOR PASSENGER SEAT HORIZONTAL MOTOR PASSENGER SEAT HORIZONTAL MOTOR (UNDER FRONT PASSENGER'S SEAT) PASSENGER SEAT REAR VERTICAL MOTOR PASSENGER SEAT RECLINE MOTOR PASSENGER SEAT RECLINE MOTOR (IN FRONT PASSENGER'S SEAT BACK) PASSENGER'S LUMBAR CIRCUIT RED WIRE RED/WHT WIRE RT/PWR/SEAT CIRCUIT BREAKER RWD TAN WIRE WHT WIRE YEL WIRE
