Heated seats circuit, w/o memory & w/ spo heated seats for GMC Acadia I facelift (2013-2016)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DRIVER BACK HEATED SEAT ELEMENT DRIVER CUSHION HEATED SEAT ELEMENT DRIVER HEATED SEAT CONTROL MODULE (UNDER DRIVER'S SEAT) DRV BACK CUSHION HEAT DRV BACK CUSHION HEAT IND DRV BACK HEAT DRV BACK HEAT IND DRV HEAT ELEMENT VOLT DRV HIGH HEAT IND DRV LOW HEAT IND DRV MEDIUM HEAT IND DRV SEAT BACK HEAT DRV SEAT BACK TEMP GRN WIRE GROUND GRY WIRE HEATED SEAT BACK TEMP HEATED SEAT CUSHION HOT AT ALL TIMES HTD/COOL SEAT FUSE I/P FUSE BLOCK LF CUSHION TEMP LOW REF LOW SPEED GMLAN LT BLU WIRE LT GRN WIRE PASS BACK CUSHION HEAT PASS BACK CUSHION HEAT IND PASS BACK HEAT PASS BACK HEAT IND PASS CUSHION HEAT PASS CUSHION TEMP PASS HEAT ELEMENT VOLT PASS HIGH HEAT IND PASS LOW HEAT IND PASS MEDIUM HEAT IND PASS SEAT BACK HEAT PASSENGER BACK HEATED SEAT ELEMENT PNK WIRE PPL PPL PNK WIRE RED/WHT WIRE TAN WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

BACK BACK IND BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) BRN WIRE CUSHION, BACK CUSHION, BACK IND DIMMING IND DK BLU WIRE DK GRN WIRE DRIVER HEATED SEAT SWITCH GRY WIRE HEATED SEAT IND DIMMING HIGH TEMP IND LOW TEMP IND LT BLU WIRE LT PNK WIRE MEDIUM IND MEDIUM TEMP IND PASSENGER CUSHION HEATED SEAT ELEMENT PASSENGER HEATED SEAT SWITCH PNK WIRE PPL PPL/WHT WIRE TAN WIRE WHT/BLK WIRE YEL WIRE
