GMC Acadia I facelift (2013-2016) pnk ppl Wiring diagrams

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 DRV BACK CUSHION HEAT 1 2 3 4 5 6 7 8 B+ GROUND 11 12 PPL 13 14 15 16 17 PPL BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK LT DRIVER BACK HEATED SEAT ELEMENT (IN DRIVER'S SEAT BACK) DRIVER CUSHION HEATED SEAT ELEMENT (IN DRIVER'S SEAT CUSHION) DRIVER HEATED SEAT CONTROL MODULE (UNDER DRIVER'S SEAT) DRV LOW HEAT IND DRV HIGH HEAT IND LOW SPEED GMLAN GRN WIRE GRY WIRE HOT AT ALL TIMES HTD/COOL SEAT FUSE I/P FUSE BLOCK (BEHIND RIGHT END OF DASH) LF CUSHION TEMP HEATED SEAT BACK TEMP DRV BACK HEAT LT BLU WIRE LT GRN WIRE PASS BACK HEAT PASS LOW HEAT IND PASS HIGH HEAT IND PASS MEDIUM HEAT IND PASS BACK CUSHION HEAT IND PASSENGER BACK HEATED SEAT ELEMENT (IN FRONT PASSENGER'S SEAT BACK) PNK LOW REF LOW REF LOW REF LOW REF WIRE PNK PPL WIRE PNK WIRE PPL RED/WHT WIRE TAN WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 DRV BACK CUSHION HEAT 1 2 3 4 5 6 7 8 B+ GROUND 13 14 15 16 17 PPL BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK LT DRIVER BACK HEATED SEAT ELEMENT (IN DRIVER'S SEAT BACK) DRIVER CUSHION HEATED SEAT ELEMENT (IN DRIVER'S SEAT CUSHION) DRIVER HEATED SEAT CONTROL MODULE (UNDER DRIVER'S SEAT) DRV LOW HEAT IND DRV HIGH HEAT IND LOW SPEED GMLAN GRN WIRE GRY WIRE HOT AT ALL TIMES HTD/COOL SEAT FUSE I/P FUSE BLOCK (BEHIND RIGHT END OF DASH) LF CUSHION TEMP HEATED SEAT BACK TEMP DRV BACK HEAT LT BLU WIRE LT GRN WIRE PASS BACK HEAT PASS LOW HEAT IND PASS HIGH HEAT IND PASS MEDIUM HEAT IND PASS BACK CUSHION HEAT IND PASSENGER BACK HEATED SEAT ELEMENT (IN FRONT PASSENGER'S SEAT BACK) PNK LOW REF LOW REF LOW REF LOW REF WIRE PNK PPL WIRE PNK WIRE PPL RED/WHT WIRE TAN WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
