GMC Acadia I facelift (2013-2016) audio/video input adapter Wiring diagrams
This page contains all the electrical diagrams for the component. audio/video input adapter, in which he is found in the car GMC Acadia I facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram audio/video input adapter (1 of 2)
AUDIO/VIDEO INPUT ADAPTER
AUX AUDIO
AUX AUDIO LEFT SIG
AUX VIDEO HIGH SIG
BLK/WHT WIRE
BRIGHT CTRL
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRAIN WIRE
DVD VIDEO SIG (+)
ENABLE SIG
GROUND
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
I/P FUSE BLOCK
INFOTMNT FUSE
LT GRN/BLK WIRE
NCA WIRE
PNK/BLK WIRE
PPL
RADIO
RADIO CIRCUIT
RADIO ON
RED/WHT WIRE
RIGHT SIG
SERIAL DATA
VIDEO BRIGHT CTRL
VIDEO DISPLAY
VIDEO DRAIN WIRE
VIDEO MOD SIG
VIDEO SIG
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Video system circuit, without spo accessory -> AUDIO/VIDEO INPUT ADAPTER
Wiring diagram audio/video input adapter (2 of 2)
AUDIO/VIDEO INPUT ADAPTER
AUX AUDIO
AUX AUDIO LH SIG
AUX AUDIO RH SIG
AUX VIDEO -
BLK/WHT WIRE
BRIGHT CTRL
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRAIN WIRE
DRAIN WIRE PPL AUX VIDEO HI SIG
DVD VIDEO SIG (+)
ENABLE SIG
GROUND
GROUND DISTRIBUTION SYSTEM
HIGH SIG
HOT AT ALL TIMES
I/P FUSE BLOCK
INFOTMNT FUSE
LEFT SIG (-)
LT GRN/BLK WIRE
NCA WIRE
PNK/BLK WIRE
PPL
RADIO
RADIO CIRCUIT
RADIO ON
RED/WHT WIRE
RIGHT SIG
SERIAL DATA
VIDEO BRIGHT CTRL
VIDEO DISPLAY
VIDEO DRAIN WIRE
VIDEO MOD SIG
VIDEO MODULE SIG
VIDEO SIG
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Video system circuit, w/o spo accessory -> AUDIO/VIDEO INPUT ADAPTER
