Geo Tracker I (1989-1998) power input module gnd drl ind ctrl brake ind ctrl light sw sig wiring diagram
This page shows the only wiring diagram for the component.power input module gnd drl ind ctrl brake ind ctrl light sw sig, which is found in the car Geo Tracker I (1989-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
power input module gnd drl ind ctrl brake ind ctrl light sw sig wiring diagram (1 of 1)
4-DOOR 2-DOOR
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/WHT WIRE
BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR)
BRAKE INDICATOR
BULKHEAD GROMMET NEAR BRAKE MASTER CYLINDER)
CHARGE INDICATOR
COMBINATION SWITCH
DAYTIME RUNNING LAMPS CONTROL MODULE (LEFT SIDE OF I/P)
DAYTIME RUNNING LAMPS DIODE (TAPED TO MAIN HARNESS ABOVE BLOWER MOTOR)
DAYTIME RUNNING LAMPS RESISTOR (INSIDE RIGHT FRONT FENDER)
DRL INDICATOR
FROM INSTR CLUSTER
FUSE BLOCK 1 (RIGHT SIDE OF ENGINE COMPT)
FUSE BLOCK 2 (UNDER LEFT I/P)
GENERATOR
GROMMET NEAR BRAKE MASTER CYLINDER)
HEAD
HEADLAMP/DIMMER SWITCH
HI LO PASS 1 10 11 HI
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON OR START
IG-COIL METER FUSE
IGNITION SWITCH BREAK OUT)
INSTRUMENT PANEL CLUSTER ASSEMBLY
J/C 2 (BEHIND ILLUMINATION CONTROLLER)
LEFT HEADLAMP
LEFT HEADLAMP FUSE
ORG/WHT WIRE
PARK OFF
PARKING BRAKE SWITCH (IN CENTER CONSOLE)
PASS
PNK/BLU WIRE
PNK/WHT WIRE
POWER INPUT MODULE GND DRL IND CTRL BRAKE IND CTRL LIGHT SW SIG
PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT HEADLAMP
RIGHT HEADLAMP FUSE
SWITCH BREAK OUT)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/RED WIRE
