Geo Tracker I (1989-1998) off on off off Wiring diagram
This page shows the only wiring diagram for the component.off on off off, which is found in the car Geo Tracker I (1989-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off on off off (1 of 1)
4 5 6 3 (1995) (1996)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
FUSE BLOCK (LEFT OF STEERING COLUMN)
GRN WIRE
HOT IN ON AND START
OFF ON OFF OFF
ON ON OFF
ORG/ WIRE
PARK MOTOR
REAR WASHER PUMP (WASHER FLUID RESERVOIR)
REAR WASHER SWITCH
REAR WIPER MOTOR (CENTER OF BACK DOOR)
REAR WIPER SWITCH
REAR WIPER/ WASHER SWITCH
RED WIRE
RUN WIRE
WIPER/ WASHER FUSE
YEL WIRE
YEL/BLU WIRE
Go to component -> Rear washer/wiper circuit -> OFF ON OFF OFF
