Geo Tracker I (1989-1998) from ignition switch conn break out) Wiring diagram
This page shows the only wiring diagram for the component.from ignition switch conn break out), which is found in the car Geo Tracker I (1989-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from ignition switch conn break out) (1 of 1)
6-PIN CONN BEHIND LEFT REAR WHEELHOUSING)
BLK WIRE
BLOWER SPEED SELECTOR SWITCH CONN BREAK OUT)
BLU WIRE
BREAK OUT TO 6-PIN CONN BEHIND LEFT REAR WHEELHOUSING)
BREAK OUT-4 DOOR)
BREAK OUT-4 DOOR) (2 DOOR)
BREAK- OUT)
CENTER HIGH MOUNT STOPLAMP
COMBINATION SWITCH
FROM BREAK OUT TO 6-PIN CONN BEHIND LEFT REAR WHEELHOUSING- 2 DOOR)
FROM IGNITION SWITCH CONN BREAK OUT)
FROM LEFT KICK PANEL GROMMET-2 DOOR)
FROM MAF/IAT SENSOR BRANCH BREAK OUT)
FUSE BLOCK 2 (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD FUSE
HAZARD SWITCH
HEAD
HEADLAMP RELAY 2
HEADLIGHT DIMMER SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL CLUSTER ASSEMBLY
LEFT FRONT PARK/ TURN LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LEFT REAR SIDE MARKER LAMP
LEFT TURN INDICATOR
OFF
ON OFF
OUT-4 DOOR)
PARK
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT PARK/ TURN LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
RIGHT REAR SIDE MARKER LAMP
RIGHT TURN INDICATOR
SPLICES: 2-DOOR/4-DOOR
STOP/ HORN FUSE
STOPLAMP SWITCH (ABOVE BRAKE PEDAL)
STOPLAMP SWITCH CONN BREAK OUT)
SWITCH CONN BREAK OUT)
TAIL DOME FUSE
TAIL/ STOP LAMP
TAIL/ STOP- LAMP TURN LAMP
TRAILER CONNECTOR (BEHIND LEFT REAR WHEEL HOUSING)
TRANSMISSIONS, INTERIOR LIGHTS SYSTEMS
TURN BACK FUSE
TURN LAMP
TURN SIGNAL SWITCH
TURN/ HAZARD RELAY
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> FROM IGNITION SWITCH CONN BREAK OUT)
