Geo Prizm II (1992-1997) throttle angle sensor Wiring diagram

1.6L A/T 1.8L A/T M/T 1.6L VIN 6 ONLY 1.8L VIN 8 ONLY 1.8L W/ A/T ONLY 19 18 PPL PPL A/T ANTI-LOCK BRAKES SYSTEM AUDIO ALARM MODULE BLK (OR BLK/WHT) WIRE BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR) BRN WIRE BRN/YEL WIRE CLUTCH PEDAL POSITION INTERRUPT SWITCH CRUISE CONTROL ACTUATOR (RIGHT SIDE OF ENGINE, ABOVE WHEEL WELL) CRUISE CONTROL DIODE (BEHIND INSTRUMENT CLUSTER) CRUISE CONTROL ECU (BELOW RADIO) CRUISE CONTROL SWITCH CRUISE INDICATOR DC SERVO MOTOR ECU-B FUSE ECU-IG FUSE ENGINE CONTROL MODULE ENGINE CONTROLS OR TRANSMISSION SYSTEM (SHIFT SOLENOID #2) (1.8L W/ A/T ONLY) ENGINE CONTROLS SYSTEM (SENSOR GNDS) EXTERIOR LIGHTS SYSTEM (STOP LAMPS) GAUGE FUSE GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START IDL IDLE SIG CTRL IDLE SWITCH IDLE INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM (SPEEDOMETER) J/B 1 (BEHIND LEFT KICK PANEL) J/B 2 (BEHIND RIGHT KICK PANEL) J/B 3 (BEHIND CENTER OF I/P) J/C 3 (ATTACHED TO J/B 3- (BEHIND LEFT KICK PANEL) LAMP DRIVER MOD BREAK OUT) LT GRN WIRE MAGNETIC CLUTCH MC MO GND IGN MEM STOP O/D CUT SIG PARKING BRAKE SWITCH (CENTER CONSOLE) POWERTRAIN CONTROL MODULE PPL DIAG OD CUT PPL TC DATA LINK CONNECTOR (PARTIAL) (ON LEFT FRONT STRUT TOWER) PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RESUME/ ACCEL SENS IN RTN SENSOR GND SET/ COAST SHIFT INTERLOCK SYSTEM STARTING/CHARGING STSTEM (IGNITION SWITCH-START, CLUTCH PEDAL POSITION SWITCH) STARTING/CHARGING STSTEM (IGNITION SWITCH-START, PARK/NEUTRAL POSITION SWITCH) STOP FUSE STOPLAMP SWITCH SUPPLEMENTAL RESTRAINT SYSTEM COIL ASSEMBLY (COMBINATION SWITCH) THROTTLE ANGLE SENSOR THROTTLE POSITION SWITCH VS IN W/ M/T ONLY WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE
